DRA#-Input ACC IEC 60870-5-103 meaning
32 87 Private range
33 88 Private range
34 89 Private range
35 90 Private range
36 91 Private range
37 92 Private range
38 93 Private range
39 94 Private range
40 95 Private range
20.6.3 Function and information types
Product type IEC103mainFunType value Comment:
REL 128 Compatible range
REC 242 Private range, use default
RED 192 Compatible range
RET 176 Compatible range
REB 207 Private range
REG 150 Private range
REQ 245 Private range
RER 152 Private range
RES 118 Private range
Refer to the tables in the Technical reference manual /Station communication,
specifying the information types supported by the communication protocol IEC
60870-5-103.
To support the information, corresponding functions must be included in the
protection IED.
There is no representation for the following parts:
• Generating events for test mode
• Cause of transmission: Info no 11, Local operation
Glass or plastic fibre should be used. BFOC/2.5 is the recommended interface to use
(BFOC/2.5 is the same as ST connectors). ST connectors are used with the optical
power as specified in standard.
Section 20 1MRK 502 071-UEN -
Station communication
710 Generator protection REG670 2.2 IEC and Injection equipment REX060, REX061, REX062
Application manual
