ABB REG670 Applications Manual

IEC 61850 or
function name
ANSI Function description Generator
REG670
(Customized)
REG670 (A20) REG670 (B30)
REG670 (C30)
Metering
PCFCNT Pulse-counter logic 16 16 16 16
ETPMMTR Function for energy calculation and
demand handling
6 6 6 6
2.5 Communication
IEC 61850 or function
name
ANSI Function description Generator
REG670
(Customized)
REG670 (A20) REG670 (B30)
REG670 (C30)
Station communication
LONSPA, SPA SPA communication protocol 1 1 1 1
ADE LON communication protocol 1 1 1 1
HORZCOMM Network variables via LON 1 1 1 1
RS485GEN RS485 1 1 1 1
DNPGEN DNP3.0 communication general
protocol
1 1 1 1
CHSERRS485 DNP3.0 for EIA-485 communication
protocol
1 1 1 1
CH1TCP, CH2TCP,
CH3TCP, CH4TCP
DNP3.0 for TCP/IP communication
protocol
1 1 1 1
CHSEROPT DNP3.0 for TCP/IP and EIA-485
communication protocol
1 1 1 1
MSTSER DNP3.0 serial master 1 1 1 1
MST1TCP,
MST2TCP,
MST3TCP,
MST4TCP
DNP3.0 for TCP/IP communication
protocol
1 1 1 1
DNPFREC DNP3.0 fault records for TCP/IP and
EIA-485 communication protocol
1 1 1 1
IEC 61850-8-1 IEC 61850 1 1 1 1
GOOSEINTLKRCV Horizontal communication via
GOOSE for interlocking
59 59 59 59
GOOSEBINRCV GOOSE binary receive 16 16 16 16
GOOSEDPRCV GOOSE function block to receive a
double point value
64 64 64 64
Table continues on next page
Section 2 1MRK 502 071-UEN -
Application
52 Generator protection REG670 2.2 IEC and Injection equipment REX060, REX061, REX062
Application manual
