Single
command
function
SINGLECMD
CMDOUTy
OUTy
Function n
en04000207.vsd
Function n
IEC04000207 V2 EN
Figure 299: Application example showing a logic diagram for control of built-in
functions
Single
command
function
SINGLESMD
CMDOUTy
OUTy
Device 1
User-
defined
conditions
Configuration logic circuits
en04000208.vsd
&
IEC04000208 V2 EN
Figure 300: Application example showing a logic diagram for control of external
devices via configuration logic circuits
15.10.3 Setting guidelines
The parameters for Single command, 16 signals (SINGLECMD) are set via the local
HMI or PCM600.
1MRK 502 071-UEN - Section 15
Control
Generator protection REG670 2.2 IEC and Injection equipment REX060, REX061, REX062 597
Application manual
