Arris CHP Max5000 User Manual

1508685 Rev D CHP Max Monitorable Attributes A-15
ANSI/SCTE 38-1 2009
(formerly HMS 026)
Hybrid Fiber/Coax Outside Plant Status Monitoring SCTE-HMS-PROPERTY-MIB
Management Information Base (MIB) Definition
http://www.scte.org/documents/pdf/standards/ANSI_SCTE%2038-1%202009.p
df
http://www.scte.org/documents/standards/approved/hms023R14.txt
ANSI/SCTE 38-11
2008
(formerly HMS 114)
HMS Headend MIB: SCTE-HMS-HEADENDIDENT-MIB
http://www.scte.org/documents/pdf/standards/ANSI_SCTE%2038-11%202008.
pdf
http://www.scte.org/documents/mib/HMS114R11_wg1.txt
MIB used for downloading the SMM images to the module
ANSI/SCTE 38-8 2009
(formerly HMS 063)
Hybrid Fiber/Coax Outside Plant Status Monitoring
SCTE-HMS-DOWNLOAD-MIB definition
http://www.scte.org/documents/pdf/standards/ANSI_SCTE%2038_8%202009.p
df
http://www.scte.org/documents/mib/hms063R6.mib%20pre-final%201-11.txt
Following MIBs are used by Inside Plant headend equipment to manage CHP modules
ANSI/SCTE 83-1 2006
(formerly HMS 108)
HMS Inside Plant MIB Part 1: SCTE-HMS-HE-OPTICS-MIB
http://www.scte.org/documents/pdf/standards/ANSI_SCTE%2083_1%202006.p
df
http://www.scte.org/documents/mib/HMS108R13.mib
ANSI/SCTE 83-4 2009
(formerly HMS 133)
HMS Common Inside Plant MIB SCTE-HMS-HE-RF-MIB
http://www.scte.org/documents/pdf/standards/ANSI_SCTE%2083_4%202009.p
df
http://www.scte.org/documents/mib/HMS133R1.txt
ANSI/SCTE 84-1 2009
(formerly HMS 111)
HMS Common Inside Plant MIB Part 1: SCTE-HMS-HE-COMMON-MIB
http://www.scte.org/documents/pdf/standards/ANSI_SCTE%2084_1%202009.p
df
http://www.scte.org/documents/mib/HMS111R9.mib
ANSI/SCTE 84-2 2009
(formerly HMS 116)
HMS Inside Plant MIB SCTE-HMS-HE-POWER-SUPPLY-MIB
http://www.scte.org/documents/pdf/standards/ANSI_SCTE%2084_2%202009.p
df
http://www.scte.org/documents/mib/SCTE-HMS-HE-POWER-SUPPLY_MIB.txt
ANSI/SCTE 84-3 2009
(formerly HMS 117)
HMS Inside Plant MIB SCTE-HMS-HE-FAN-MIB
http://www.scte.org/documents/pdf/standards/ANSI_SCTE%2084_3%202009.p
df
http://www.scte.org/documents/mib/SCTE-HMS-HE-FAN-MIB.txt
ANSI/SCTE 85-1 2009
(formerly HMS 112)
HMS HE Optics MIB Part 1: SCTE-HMS-HE-OPTICAL-TRANSMITTER-MIB
http://www.scte.org/documents/pdf/standards/ANSI_SCTE%2085_1%202009.p
df
http://www.scte.org/documents/mib/HMS112R10.txt
Table A.14 Standard HMS MIBs (cont’d)
MIB Name Description
1

Arris CHP Max5000 Specifications

General

Product Type	Multi-service Platform
Input Impedance	75 ohms
Forward Path Bandwidth	54-1002 MHz
Management	SNMP
Frequency Range Downstream	54-1002 MHz
Modulation Downstream	QAM
Modulation Upstream	QAM
Operating Temperature	0°C to 50°C
Dimensions	19"

Summary

CHP Max5000 Chassis (Rear Fiber Version) - Equipment Description and Installation

CHP Max5000 Chassis Equipment Description

Describes the CHP Max5000 chassis, including its mounting, modules, fans, and cooling mechanisms.

CHP Chassis Installation Procedures

Provides step-by-step instructions for installing the CHP chassis into a standard EIA 19-inch rack.

CHP Max AC Power Supply - Description, Installation, and Specifications

CHP Max AC Power Supply Equipment Description

Describes the CHP Max AC power supply, its models, features, and power output capabilities.

Installing and Removing the AC Power Supply Module

Provides instructions for installing and removing the AC Power Supply module, including hot-swapping.

Setting Major and Minor Alarm Thresholds for AC Power Supply

Updating AC Power Supply Module Firmware

Covers procedures for updating the AC power supply module's microcontroller firmware using Craft Management Software.

CHP Max DC Power Supply - Description, Installation, and Specifications

CHP Max DC Power Supply Equipment Description

Describes the CHP Max DC power supply, its models, features, and power output capabilities.

Installing and Removing the DC Power Supply Module

Provides instructions for installing and removing the DC Power Supply module, including connections.

Setting Major and Minor Alarm Thresholds for DC Power Supply

Updating DC Power Supply Module Firmware

Covers procedures for updating the DC power supply module's firmware using Craft Management Software.

CHP Max Element Management Modules (CMM, CMM-1, SMM, SMM-1)

Local Monitoring and Auto Configuration Features

CMM/SMM Equipment Description and Indicators

Installation and Replacement of CMM or SMM Modules

Provides instructions for installing and replacing CMM or SMM modules in the chassis.

Management Module Configuration and Password Reset

Covers configuration steps, network cabling, IP addressing, and password reset procedures.

Updating CHP-CMM and SMM/SMM-1 Firmware

Details procedures for updating the microcontroller firmware for CMM and SMM modules.

System Management Module 2 (SMM-2) - Features and Configuration

SMM-2 Auto Config and Remote Monitoring

SMM-2 Equipment Description and Indicators

SMM-2 Installation and Communication Connections

Covers SMM-2 installation, network information, and connection methods (TELNET, USB).

SMM-2 CLI Commands and IP Address Configuration
