Version 7.0 15 Mediant 3000
Hardware Installation Manual 3. Physical Description
3.1.2 Rear Panel Description
The main components of the device's rear panel (without RTMs) are shown below:
Figure 3-2: Chassis Rear Panel
Notes:
• For clarity, the figure above displays the device without communication blades.
• Depending on the ordered configuration (e.g., AC or DC power system), your device
may differ from the figure above.
Table 3-2: Rear-Panel Description
Item # Component Description
1
Two Power Entry Modules (PEM).
2
Latches and screws to secure blades and modules to chassis.
3
Slots (currently covered with blank panels) for housing the RTMs.
4
ESD terminal lug.
5
Earthing terminal (one-hole G-32 lug and 6-8 AWG wire).
