Version 7.0 29 Mediant 3000
Hardware Installation Manual 3. Physical Description
3.4.1 TP-8410 LEDs Description
The TP-8410 blade provides LEDs on its front panel, which indicates various operational
status of the blade.
3.4.1.1 Blade Operating Status LEDs
The LEDs providing operational status of the TP-8410 is described in the table below.
Table 3-10: Blade Operating Status LEDs Description
Label Color Status Description
FAIL Red
On Blade failure (fatal error).
-
Off Normal operation.
ACT Green
On Active blade.
Note: Applicable only to the HA mode.
Yellow
Blinking Redundant blade in standby mode.
Note: Applicable only to the HA mode.
-
Off Standalone blade (i.e., for Simplex configuration).
PWR Green
On Blade is receiving power.
-
Off No power is received by the blade.
SWAP
READY
Blue
On The blade can now be fully removed or inserted.
-
Off The blade has been inserted successfully.
