3.2.2.2 Chassis with TP-8410 Blades
The slot assignment for blades and RTMs in the chassis for TP-8410 is described in the
table below.
Table 3-5: Slot Assignment for Mediant 3000 with TP-8410
Chassis
Panel
Slot # Simplex Mode HA Mode
Front
1 TP-8410 blade Active TP-8410 blade
2 SA/M3K blade Active SA/M3K blade
Note: This blade operates with the
TP-8410 blade in Slot #1.
3 Slot covered by a blank panel Standby (redundant) TP-8410 blade
4 Slot covered by a blank panel Standby SA/M3K blade
Note: This blade operates with the
TP-8410 blade in Slot #3.
Rear
1 Slot covered by a blank panel Slot covered by a blank panel
2 RTM-8410 type providing one of
the following interfaces:
 16 Spans: single SCSI
connector for 16 E1/T1 spans
and two RJ-45 connectors for
GbE interfaces
 42 Spans: two SCSI
connectors for 1-42 E1/T1
spans and two RJ-45
connectors for GbE interfaces
 84 Spans: two SCSI
connectors for 1-42 E1/T1
spans and two RJ-45
connectors for GbE interface
(same as for 42 spans)
Note: Trunks 43-84 are
connected to the RTM-8410 in
Slot #4.
RTM-8410 type providing one of the
following interfaces:
 16 Spans: s
ingle SCSI connector
for 16 E1/T1 spans and two RJ-
45 connectors for GbE interfaces
 42 Spans: two SCSI connectors
for 1-42 E1/T1 spans and two RJ-
45 connectors for GbE interfaces
 84 Spans: two SCSI connectors
for 1-42 E1/T1 spans and two RJ-
45 connectors for GbE interface
(same as for 42 spans)
Note: Trunks 43-84 are
connected to the RTM-8410 in
Slot #4.
3 Slot covered by a blank panel Slot covered by a blank panel
4 RTM-8410 type providing one of
the following interfaces:
 16 Spans: slot covered by a
blank panel
 42 Spans: Two SCSI
connectors and two RJ-45
connectors for GbE interfaces
Note: The SCSI ports are not
used.
 84 Spans: Two SCSI
connectors for E1/T1 spans
and two RJ-45 connectors for
GbE interfaces
RTM-8410 type providing one of the
following interfaces:
 16 Spans: RTM-8410 providing
only two RJ-45 connectors for
GbE interfaces
 42 Spans: two SCSI connectors
and two RJ-45 connectors for
GbE interfaces
Note: The SCSI ports are not
used.
 84 Spans: Two SCSI connectors
for E1/T1 spans and two RJ-45
connectors for GbE interfaces
