AudioCodes Mediant 3000 Hardware Installation Manual

Version 7.0 39 Mediant 3000
Hardware Installation Manual 3. Physical Description
3.8.1 AC Power System
The AC power system is powered from two AC redundant feeds (providing 1+1 power
redundancy) and consists of the following hardware components:

Power Entry Module (PEM/AC/3K) – see Section 3.8.1.1 on page 40

Power Supply Module (PS/AC/3K) – see Section 3.8.1.2 on page 41
The table below lists the device's AC power specifications.
Table 3-16: AC Power Supply Specifications
Parameter Value
Power Requirements
Universal 100-240 VAC input at a nominal 50/60 Hz line
frequency, and power factor correction
Power Consumption
Depends on installed blade and configuration:
 TP-6310 OC-3/STM-1 Simplex:

2.1A @ 110VAC, 235W

1A @ 230VAC, 235W
 TP-6310 OC-3/STM-1 HA:

3.4A @ 110VAC, 373W

1.6A @ 230VAC, 373W
 TP-8410 Simplex 24 E1/T1:

1.5A @ 110VAC, 162W

0.7A @ 230VAC, 162W
 TP-8410 HA 24 E1/T1:

2.1A @ 110VAC, 230W

1A @ 230VAC, 230W
 TP-8410 Simplex 63 E1/84 T1:

2.1A @ 110VAC, 230W

1A @ 230VAC, 230W
 TP-8410 HA 63 E1/84 T1:

3.3A @ 110VAC, 336W
 1.6A @ 230VAC, 336W
Connection Provisions
PEM module with 3-prong AC inlet
