17
Preparation
Slide-on Table
The slide-on table increases the sewing surface.
Attaching the Table
raise the needle and presser foot ►
from the left, push table to the right over the free-arm ►
and push firmly so that it engages over the fixing cam
Removing the Table
raise needle and presser foot ►
press the button down and remove to the left ►
Seam Guide
press the release button and insert into the groove ►
(underside of table) from left or right
can be moved over the entire table length ►
Scale
«0» corresponds to the center needle position ►
Thread Cutter
on Head Frame
pull both threads from back to front over the cutter ►
threads release automatically as soon as the first stitch ►
is sewn
at bobbin winder
after winding bobbin, pull thread in direction of arrow ►
over thread cutter
Remove the slide-on table only when
bobbin cover is closed.
