00.9
Attachment of control cam of large hand le-
ver, locking fluid
Nm 2 LOCTITE 243
Stand to frame Nm 41
Switch (easy-lift mechanism) stand to frame Nm 8
Spring holder (easy-lift mechanism) to frame Nm 21
Bowden cable retaining bracket to frame Nm 21
Lock of Bowden cable Nm 8
Auxiliary swing arm to powertrain cradle Nm 21
Eyebolt to frame Nm 8
Shoulder bar
Seat to frame Nm 21
Head restraint to frame Nm 21
Shoulder bar, top, to frame M10 Nm 41
Shoulder bar, top, to frame M8 Nm 21
Shoulder bar, bottom, to frame M6 (clamp-
ing screw)
Nm 9
Roof frame
Front roof bar (clamp) Nm 21
Rear roof bar (clamp) Nm 21
Roof frame cross brace Nm 21
Mirror brackets Nm 5
Luggage system
Top bracket to frame Nm 8
Bracket to rear frame Nm 21
Top bracket to bracket Nm 21
Lock carrier Nm 5
Head restraint to frame Nm 21
Model C1
Connection
51 Equipment
Ignition lock to frame Nm 9
Seat latch Nm 9
Seat bench lock to left rear side panel Nm 3
Striker on rear storage compartment Nm 3
Lock cylinder on rear storage compartment Nm 7
Striker of storage compartment Nm 3
Lock cylinder on storage compartment Nm 7
Lock bolt for luggage rail Nm 3
Model C1
Connection
46 Frame
