33.7
Replacing spring/shock absorber
– Remove spring strut
e
Attention:
The spring strut is spring-loaded: proceed carefully
when disassembling - injury hazard!
•
Compress spring with
device (3),
BMW No. 33 5 600
,
adapter (2),
BMW No. 33 5 652
,
adapter (1),
BMW No. 33 5 606
•
Remove retaining plate (arrow)
•
Release and remove spring
When installing:
•
While installation is basically a reversal of the re-
moval process, careful attention should be di-
rected toward the following:
•
Install end of spring opposite slot in the retaining
plate, ensuring that the entire end of the spring
seats securely against the plate
•
Check spring to ensure correct installation
C1330040
33 5 600
33 5 652
33 5 606
2
1
3
C1330010
