11.14
When installing:
•
Install the cylinder head cover before installing
the powertrain cradle
e
Attention:
Make sure that gasket and cover are free of oil!
•
Installing cylinder head cover
e
Attention:
When lowering watch the struts and the duct to the
air plenum chamber!
L
Note:
Make sure the detent for the long lever of the easy-
lift mechanism engages! If necessary, move the le-
ver to the drive position first, and then move it to the
park position!
X
Tightening torque:
Cylinder head cover ..................................... 10 Nm
Strut, bottom ................................................ 21 Nm
Lock engine at TDC
•
Loosen hose clamp (arrow) on intake-air plenum
chamber
L
Note:
Watch for dirt and contamination adjacent to the
starter/threaded plug (arrow) - do not allow contam-
inants to enter the engine!
•
Undo the Allen bolt adjacent to the starter and
use set bolt,
BMW No. 11 7 651,
to lock the en-
gine at TDC
C1130010
C1000200
11 7 651
C1000220
