31.12

•

Unbolt (arrow) ABS wheelspeed sensor

•

Remove ABS wheelspeed sensor (1)

•

Detach (arrow) bracket for brake hose/sensor

connection wire at telescopic tube cross brace

Attention:

The fasteners are secured with thread-locking com-

pound; heat to max. 120 °C (248 °F) to facilitate re-

moval!

•

Using an angled 21 mm box-end spanner and Al-

len wrench,

BMW No. 31 5 603

, release fastener

(arrow) securing leading link to fork cross brace

Note:

Telescopic fork oil can run out!

Stationary tubes remain on vehicle!

•

Remove telescopic tube cross brace complete

with telescopic tubes and front wheel by extract-

ing downward

•

Drain off the telescopic fork oil

C1310010

C1310020

31 5 603

C1310040
