Bosch DIVAR AN 5000 User Manual

Exporting
DVD (optional) Built-in DVD+R/RW writer
USB Flash memory or external HDD (FAT32)
e-SATA Flash memory or external HDD (FAT32)
Network Bosch Video Client or Web Client software
Mechanical
Dimensions (WxDxH) 440 x 420 x 70 mm (17.3 x 16.5 x 2.8 in)
excluding cabling and feet (5 mm)
Rack mount kit (included) For mounting one unit in an EIA 19” rack
Weight 5.5 kg (12.13 lb) approx.
excluding HDD(s) and DVD writer
Environmental
Temperature (incl. HDD(s) and DVD writer)
Operating +0°C to +40°C (+32°F to +104°F)
Storage -40°C to +70°C (-40°F to +158°F)
Humidity
Operating <93% non-condensing
Storage <95% non-condensing
Standards and Directives
Standards
EMC Directive 2004/108/EC
EMC Immunity EN 50130‑4:2011 *
EMC Emission EN 55022:2010, +AC:2011. Class B conducted + radiated emission
EN 61000-3-2:2006, +A1: 2009, +A2:2009 Mains harmonics
EN 61000-3-3:2008. Voltage fluctuations
Environment EN 50130-5 Class 1
Low voltage directive 2006/95/EC
Safety EN 60950-1:2006, +A11:2009, +A1:2010, +A12:2011, +AC:2011
USA: UL 60950-1: 2nd edition 2011-12-19
CAN/CSA-C22.2 No.60950-1-07, 2nd edition 2011-12
12.3
154 en | Technical specifications DIVAR AN 3000 / DIVAR AN 5000
2014.10 | 2.0 | AM18-Q0669 Operations Manual Bosch Security Systems

Bosch DIVAR AN 5000 Specifications

General

Motion sensor	Yes
Total storage capacity	2000 GB
Video compression formats	H.264
Analog signal format system	NTSC, PAL
Compatible operating systems	Windows XP, Windows Vista, Windows 7.
Playback resolutions supported	960x576, 960x480, 704x576, 704x480, 704x288, 704x240, 352x288, 352x240, 176x144, 176x120
Audio input	4
BNC input ports	16
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
HDD interface	Serial ATA
Maximum HDD capacity	3000 GB
Power requirements	100-240VAC 50-60Hz
Optical drive included	No
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 93 %

Weight and Dimensions

Dimensions (WxDxH)	440 x 420 x 70 mm
