Play previous In playback mode, playback the previous video
In text mode or when choosing a camera channel, input
number 7 (only on DIVAR AN 3000 )
Reverse/Pause In normal playback or pause mode, click to reverse playback
In reverse playback, click to pause playback
In text mode or when choosing a camera channel, input
number 1 (only on DIVAR AN 3000 )
Play Next In playback mode, playback the next video
In menu setup, scroll down the dropdown list
In text mode or when choosing a camera channel, input
number 8 (only on DIVAR AN 3000 )
Play/Pause In normal playback, click to pause playback
In pause mode, click to resume playback
In text mode or when choosing a camera channel, input
number 2 (only on DIVAR AN 3000 )
The DIVAR 5000 also has the following buttons
Export Export the currently selected files to an external device
Sequence Activate the camera views in a pre-set sequence
Numeric keypad Switch camera channels
In text mode, enter characters in a field (use the Shift
button to change the input mode)
The front panels also have the following status lights and a USB connector:
Status lights
Symbol Function
Channel record 1-16 A channel number is lit if the channel is recording.
Hard disk Is lit if an installed hard disk has an error or is full.
Network Is lit if a user is connected to the DVR online.
USB port Connect USB storage device or USB mouse to this port.
Remote control
All functions controlled by the front panel and USB mouse can, alternatively, be accessed
using the supplied remote control.
The IR remote control allows control of up to 999 units without interfering with one another.
An ID number must be chosen on the remote control and in the system (see menu Setting >
General for setting a system ID for each unit).
To set the ID on the remote control:
1. Press the Add button on the remote control.
7.1.3
DIVAR AN 3000 / DIVAR AN 5000 Operating instructions | en 87
Bosch Security Systems Operations Manual 2014.10 | 2.0 | AM18-Q0669
