Trouble Shooting Information for C7000VP series
5.2 Specifications for staple capacity of Finisher-AB1/AB2
Description
The following are specifications for staple capacity of Finisher-AB1/AB2 by basis weight of
paper (both small and large sizes).
# of sheets applicable (Small size / Large size)
Cover and back cover only
Note:
- Thickness of stack has to be less than 11mm for small size, and less than 5.5mm for large
size.
- Length of paper in feeding direction has to be as follows.
For large size: 216.1mm to 482.7mm (e.g. 13x19, 12x18, SRA3, A3, B4, A4R, B5R,
LDR, LGL, LTRR, EXER)
For small size: shorter then 216mm (e.g. A4, B5, A5R, LTR, EXE, STMTR)
Reference:
Although the staple capacity of the aforementioned Finisher units is specified like the above, on
requests from the field, the units were so designed that they staple more than the number of
sheets described above with regard to all basis weights in case the total number of sheets to be
stapled is set within 100 sheets. But, please be informed that a problem may occur when the
units staple more than the number specified above.
5.3 Number of sheets and size specification for saddle stitching
Description
- Paper size applicable for saddle stitching:
12 x 18, SRA3 (320 x 450), A3, B4, A4R, LDR, LTRR, LGL
- Basis weight:
Inner sheets: 64 to 200g/mx2
Cover: 64 to 300g/x2
- Maximum number of sheets for binding:
20 sheets (Inner sheets (64 to 80g/mx2) 19 sheets + Cover (64 to 300g/mx2) 1 sheet
2 to 20 sheets (incl. cover)
2 to 15 sheets (incl. cover)
2 to 5 sheets (incl. cover)
2 to 15 sheets (incl. cover)
2 to 10 sheets (incl. cover)
2 to 5 sheets (incl. cover)
