Trouble Shooting Information for C7000VP series
1.23 E805-0404
Description
There are some reported instances from the field where the machine was restored from the
error code E805-0404 after replacement of the fixing/feeder driver assembly (FM2-2260).
- E805-0404 can be displayed when the pre-fixing feed rear left fan (FM137) error occurs.
FM137 is used to attract paper to the pre-fixing feed belt.
Note:
When this error code occurs, after taking the appropriate remedy, turn the main power switch
ON and then execute the following service mode: service mode > COPIER > Function >
CLEAR > ERR. After that, turn the main power switch OFF/ON so that the error code will be
cleared. Be sure to turn the switch of the pick-up/delivery optional equipment ON first, and then
the main engine. Otherwise, the machine fails to recognize the optional equipment.
Reference:
The error codes that require the error clear operation are as follows: E000, E001, E002, E003,
E004, E013, E717, and E719.
Field Remedy
1. Re-fit J1557 connector of the fixing/feeder driver PCB.
2. Re-fit the connectors J5449, J7405, and J7400 between the fan FM137 and J1557 of the
fixing/feeder driver PCB.
3. If the symptom still occurs, replace the fixing/feeder driver PCB with a now one.
FM2-2260 Fixing/feeder Driver PCB Assembly
