Handling rolls
Loading Rolls in the Roll Feed Unit
1. Open the Roll Paper Unit Cover .
2. With the edge of the roll paper facing up toward you, insert the Roll Holder shaft into the guide
grooves (a) of the Roll Holder Slot on both sides. Make sure that the colors of the Roll Holder
shaft ends (b) and the guide grooves match.
Caution
• Be careful not to pinch your ngers between the guide grooves (a) and the Roll Holder shaft
(b) when loading rolls.
Note
• If it is dif cult to load rolls from the front, load them from behind the printer .
Handling Paper 1 19
To Next Page
