Print quality and color settings
Choosing the Document T ype and Printing Conditions
(W indows)
Y ou can specify your own print settings instead of using the Print T arget presets. This topic describes how
to print CAD drawings in monochrome.
1. Choose Print in the application menu.
2. Select the printer in the dialog box, and then display the printer driver dialog box. ( → P .473)
3. Make sure the Main sheet is displayed.
4. In the A Media T ype list, select the type of paper that is loaded.
5. Click D Advanced Settings to switch the print mode.
6. Click Line Drawing/T ext in the E Print Priority list.
7. Click Standard (600dpi) in the F Print Quality list.
Note
• Options displayed in the F Print Quality list vary depending on the paper type.
190 Enhanced Printing Options
