Note
• To display the Paper Information on Printer dialog box, on the Main sheet, click Get Information by Media
Type. (See "Main Sheet .") ➔ P.150
•
A Paper Source
Shows the paper source supported by the printer, as well as information about the loaded paper. To update the
paper source and media type settings in the printer driver, select the desired Paper Source option and click
OK.
Paper Detailed Settings Dialog Box
Paper Detailed Settings Dialog Box
In the Paper Detailed Settings dialog box, you can set Drying Time for the paper selected with Media Type of the
Main sheet, etc.
You can display this dialog box by clicking Advanced Settings of Media Type on the Main sheet. (See "Main
Sheet .") ➔ P.150
As for the items for which you can select Printer Default in this dialog box, you also can set them from the control
panel of the printer. (See "Menu Settings.") ➔ P.414
A Drying Time
Specify the time that the printer waits for ink to dry, as needed. The Between Pages setting is only valid for rolls.
• B Between Pages
You can set the time to wait after printing 1 document page until ejecting the paper. Since waiting time is re-
quired for ink to dry before a roll is cut, you can deliver paper in the Output Stacker with the ink dried even if
Cutting Mode is set to Automatic.
Setting Item Details
Printer Default The setting of the control panel of the printer is applied.
Off Paper is ejected immediately after printing completes.
30 sec. / 1 min. / 3 min. / 5 min. /
10 min. / 30 min. / 60 min.
Paper is ejected when the set time elapses after printing completes.
• C
Between Scans
You can set the time to wait after printing 1 line on a page until printing the next line. Set this to avoid bleeding
or color unevenness such as when bleeding occurs on a page or when color unevenness occurs during bor-
derless printing.
Setting Item Details
Printer Default The setting of the control panel of the printer is applied.
Off The next line is printed immediately after a line is printed.
1 sec. / 3 sec. / 5 sec. / 7 sec. / 9
sec.
The next line is printed when the set time elapses after a line is printed.
* Increase the time according to the occurrence condition of bleeding or unevenness.
Paper Detailed Settings Dialog Box iPF780
User's Guide
Windows Software Printer Driver
154

Canon imagePROGRAF iPF780 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 914.4 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Certification	RoHS
Product color	Black, Grey
Internal memory	256 MB
Sound pressure level (printing)	48 dB
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	877 mm
Width	1304 mm
Height	1062 mm
