Canon imagePROGRAF iPF780 User Manual

Preview
Preview
The Features of Preview ...............................................................................................................................................171
Starting Preview ............................................................................................................................................................... 171
Preview Main Window .................................................................................................................................................... 172
Dialog Area ......................................................................................................................................................................... 174
Enlarge/Reduce the screen display .........................................................................................................................175
Moving a Page .................................................................................................................................................................. 175
Using the ruler .................................................................................................................................................................. 175
Priority setting for rotating 90 degrees ................................................................................................................ 175
Printing with Selecting the Layout ........................................................................................................................... 177
Print on the Center ......................................................................................................................................................... 179
Not Print Spaces at the Top/Bottom ...................................................................................................................... 180
The Features of Preview
The Features of Preview
The main features of Preview are as follows.
• While viewing this screen, you can adjust layout settings of a document created with application software.
• You can not only adjust layout settings but also your changes will be instantly applied on the preview screen,
and you can print the preview screen as it is seen.
Note
• The media type, image size, detailed media settings, and the printer settings can cause the actual print output to
differ from the Preview settings.
Starting Preview
Starting Preview
Follow the procedure below to start the Preview.
1 Start the apllication software which you use.
2 From the application software's File menu, select the printer setup menu to open the Print dialog box.
Note
• Normally, select Print from the File menu.
3
On the Main sheet, click on the Open Preview
When Print Job Starts check box.
Click the OK button to save the settings.
Note
• Your printer is depicted in the lower-left area of this screen.
iPF780 The Features of Preview
User's Guide
Windows Software Preview
171

Canon imagePROGRAF iPF780 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 914.4 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Certification	RoHS
Product color	Black, Grey
Internal memory	256 MB
Sound pressure level (printing)	48 dB
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	877 mm
Width	1304 mm
Height	1062 mm
