Canon imagePROGRAF iPF780 User Manual

Print Page Rotated 90 Degrees
Print Page Rotated 90 Degrees
You can save paper by printing in landscape orientation on roll paper.
1 On the Paper Settings Panel ➔ P.269 , select Roll Paper in Paper Source.
2 On the Output Settings Panel ➔ P.272 , click the Rotate Page check box on.
3
Select Rotate Right 90 Degrees or Rotate Left 90
Degrees.
4 Click the Print button.
Printing on rotating 90 degrees begins.
Display with Fitting to the Width of the Paper
Display with Fitting to the Width of the Paper
In the preview area, you can display to the width of the paper.
1 Select Fit to Width from the tool bar.
2
Fitting to the width of the paper, it is displayed.
Display with All
Display with All
In the preview area, you can display all.
1 Select Fit Screen from the tool bar.
iPF780 Print Page Rotated 90 Degrees
User's Guide
Mac OS Software Preview
283

Canon imagePROGRAF iPF780 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 914.4 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Certification	RoHS
Product color	Black, Grey
Internal memory	256 MB
Sound pressure level (printing)	48 dB
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	877 mm
Width	1304 mm
Height	1062 mm
