Canon imagePROGRAF iPF780 User Manual

6 Press ▲ or ▼ to select IPv6 Support, and then press the OK button.
7 Press ▲ or ▼ to select On, and then press the OK button.
Important
• Once you set IPv6 Support to On, the IPv6 StlessAddrs setting takes effect.
Note
• You can also configure IPv6 StlessAddrs and DHCPv6 from the printer Control Panel.
Configuring the Printer Driver Destination (Windows)
Configuring the Printer Driver Destination (Windows)
This topic describes how to specify the printer driver destination if the printer's IP address is changed, or if you will
use the printer over a network connection instead of via USB connection.
The procedure described below is the configuration based on the LPR or Raw protocol using the standard TCP/IP
port in Windows ( Standard TCP/IP Port ).
Important
• If you will use the printer in a TCP/IP network, make sure the printer's IP address is configured correctly.
• Configuring the IP Address on the Printer ➔ P.442
Note
• This section describes the procedure in Windows 7.
1 Open the Devices and Printers window.
2 Right-click the icon of this printer and choose Printer Properties to open the printer properties window.
3 Click the Port tab to display the Port sheet.
4 Click Add Port to display the Printer Ports dialog box.
5 In the Available Port list, select Standard TCP/IP Port.
6 Click New Port.
After the wizard starts, a window is displayed for the Welcome to the Add Standard TCP/IP Printer Port
Wizard.
7 Click Next.
8 In Printer Name or IP Address, enter the printer's IP address. If the DNS is configured, you can also enter
the DNS Domain Name.
9 Follow the instructions on the screen to add a printer port.
10 Click Close to close the Printer Ports dialog box.
11 Make sure the printer port you added is displayed under Ports, and that the port is selected.
12 Click Close to close the printer properties window.
Configuring the Printer Driver Destination (Mac OS)
Configuring the Printer Driver Destination (Mac OS)
Specify the printer driver destination as follows if the printer's IP address is changed, or if you will use the printer
over a network connection instead of via USB connection.
• If you switch to printing in a TCP/IP network, or if the printer's IP address is changed, see "Configuring the Des-
tination in TCP/IP Networks ." ➔ P.449
iPF780
Conguring the Printer Driver Destination (Windows)
User's Guide
Network Setting Initial Settings
445

Canon imagePROGRAF iPF780 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 914.4 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Certification	RoHS
Product color	Black, Grey
Internal memory	256 MB
Sound pressure level (printing)	48 dB
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	877 mm
Width	1304 mm
Height	1062 mm
