Canon imagePROGRAF iPF780 User Manual

1
Click About <application name> in the Help menu of application.
2
Click the Disabled Items button in the About <appli-
cation name> dialog box.
3
If Addin imageprograf print plug-in (ipfaddinif.dll) is dis-
played in the Disabled Items dialog box, select it and click
the Enable button.
4 Close all the dialog boxes and restart the Office application.
To start from Microsoft Word
To start from Microsoft Word
Below are the steps to start Print Plug-In for Office from Microsoft Word.
1 Start Microsoft Word.
2
If Start imagePROGRAF Print Plug-In is displayed on the toolbar/
ribbon, click it.
Important
• If the imagePROGRAF Print Plug-In toolbar/ribbon is not displayed, refer to the following.
• "When Print Plug-In for Office is not displayed" ➔P.214
iPF780 To start from Microsoft Word
User's Guide
Windows Software Print Plug-In for O󱐰ce
217

Canon imagePROGRAF iPF780 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 914.4 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Certification	RoHS
Product color	Black, Grey
Internal memory	256 MB
Sound pressure level (printing)	48 dB
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	877 mm
Width	1304 mm
Height	1062 mm
