Canon imagePROGRAF iPF780 User Manual

2
Select Rotate Left or Rotate Right from the toolbar.
Alternatively, you may click on the Rotate check box
in the Format Dialog Box ➔ P.302 then select Rotate
Right or Rotate Left, and click the OK button.
Note
• When several objects are selected, you cannot select Rotate.
Laying out Objects Automatically
Laying out Objects Automatically
Click Auto Arrange in the tool bar. This automatically lays out objects. Alternatively, you may select Auto Arrange
Object from the Object menu.
Note
• The object layout order varies depending on the Order setting on the Page Setup Dialog Box ➔ P.300 .
Aligning Objects
Aligning Objects
You can align objects systematically.
1 Select multiple objects.
2 Select the align menu from the Object menu.
• Align Top
Lays out the objects, justifying them to the top.
iPF780 Laying out Objects Automatically
User's Guide
Mac OS Software Free Layout
305

Canon imagePROGRAF iPF780 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 914.4 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Certification	RoHS
Product color	Black, Grey
Internal memory	256 MB
Sound pressure level (printing)	48 dB
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	877 mm
Width	1304 mm
Height	1062 mm
