Replace the Staple Cartridge of the Stapler Unit
Introduction
When a staple cartridge of the stapler unit inside the stacker/stapler is empty, the control panel
will display a message indicating which staple cartridge must be replaced. The procedure below
describes how to replace the staple cartridge.
Required tools
Staple N1
Procedure
Replace the staple cartridge of the stapler unit
Step Action Illustration
1 Open the front door of the stacker/stapler.
2 Grab the green tab of the staple case and
pull the staple case out of the staple unit.
NOTE
When the stapler unit is at the
back and it is difficult to pull out
the staple case, turn the dial at
the bottom left-hand side to the
left to move the stapler unit.
3 Pull out the staple cartridge.
4 Insert the new staple cartridge (Staple
N1).
4
Replace the Staple Cartridge of the Stapler Unit
Chapter 14 - Maintain the print system
427
Canon varioPRINT DP line
