Cisco Catalyst 3850 series User Manual

Related Topics
Configuring Candidate BSRs (CLI), on page 159
PIMv2 Bootstrap Router, on page 133
Defining the PIM Domain Border (CLI)
Perform the following steps to configure the PIM domain border. This procedure is optional.
SUMMARY STEPS
1.
enable
2.
configure terminal
3.
interface interface-id
4.
ip pim bsr-border
5.
end
6.
show running-config
7.
copy running-config startup-config
DETAILED STEPS
PurposeCommand or Action
Enables privileged EXEC mode. Enter your password if prompted.enable
Step 1
Example:
Device> enable
Enters the global configuration mode.configure terminal
Example:
Device# configure terminal
Step 2
Specifies the interface to be configured, and enters interface configuration mode.
interface interface-id
Step 3
Example:
Device(config)# interface
The specified interface must be one of the following:
• A routed port—A physical port that has been configured as a Layer 3 port
by entering the no switchport interface configuration command. You
gigabitethernet 1/0/1
will also need to enable IP PIM sparse-dense-mode on the interface, and
join the interface as a statically connected member to an IGMP static
group. For a configuration example, see Example: Interface Configuration
as a Routed Port, on page 95
• An SVI—A VLAN interface created by using the interface vlan vlan-id
global configuration command. You will also need to enable IP PIM
sparse-dense-mode on the VLAN, join the VLAN as a statically connected
member to an IGMP static group, and then enable IGMP snooping on the
IP Multicast Routing Configuration Guide, Cisco IOS XE Release 3.6E (Catalyst 3850 Switches)
OL-32598-01 155
Configuring PIM
Configuring PIMv2 BSR
