Use the privileged EXEC commands in the following table to monitor BSR information:
Table 17: BSR Monitoring Commands
PurposeCommand
Displays information about the elected BSR.show ip pim bsr
Displays information about the BSRv2.show ip pim bsr-router
Troubleshooting PIMv1 and PIMv2 Interoperability Problems
When debugging interoperability problems between PIMv1 and PIMv2, check these in the order shown:
1
Verify RP mapping with the show ip pim rp-hash privileged EXEC command, making sure that all
systems agree on the same RP for the same group.
2
Verify interoperability between different versions of DRs and RPs. Make sure that the RPs are interacting
with the DRs properly (by responding with register-stops and forwarding decapsulated data packets from
registers).
Related Topics
PIM Versions, on page 127
Configuration Examples for PIM
Example: Enabling PIM Stub Routing
In this example, IP multicast routing is enabled, Switch A PIM uplink port 25 is configured as a routed uplink
port with spare-dense-mode enabled. PIM stub routing is enabled on the VLAN 100 interfaces and on Gigabit
Ethernet port 20.
Device(config)# ip multicast-routing distributed
Device(config)# interface GigabitEthernet3/0/25
Device(config-if)# no switchport
Device(config-if)# ip address 3.1.1.2 255.255.255.0
Device(config-if)# ip pim sparse-dense-mode
Device(config-if)# exit
Device(config)# interface vlan100
Device(config-if)# ip pim passive
Device(config-if)# exit
Device(config)# interface GigabitEthernet3/0/20
Device(config-if)# ip pim passive
Device(config-if)# exit
Device(config)# interface vlan100
Device(config-if)# ip address 100.1.1.1 255.255.255.0
Device(config-if)# ip pim passive
Device(config-if)# exit
Device(config)# interface GigabitEthernet3/0/20
IP Multicast Routing Configuration Guide, Cisco IOS XE Release 3.6E (Catalyst 3850 Switches)
OL-32598-01 181
Configuring PIM
Troubleshooting PIMv1 and PIMv2 Interoperability Problems
