ENGINE CONTROLS 1F–75
DAEWOO M-150 BL2
DTC P0118 – Engine Coolant Temperature Sensor High Voltage
Step Action Value(s) Yes No
1
Perform an Euro On-Board Diagnostic (EOBD)
System Check.
Is the system check complete?
–
Go to Step 2
Go to
“On-Board
Diagnostic
System Check”
2
1. Connect the scan tool to the data link connector
(DLC).
2. Run the engine until it reaches operating
temperature.
Does the scan tool show the ECT sensor reading
within the value specified?
80~110°C
(176~230°F)
Go to
“Diagnostic
Aids” Go to Step 3
3
1. Turn the ignition switch to LOCK.
2. Disconnect the ECT sensor connector.
3. Turn the ignition switch to ON.
Does the scan tool show the ECT sensor reading
within the value specified? ≥ -30°C Go to Step 4 Go to Step 6
4
1. Jumper the ECT sensor signal circuits at terminal
B and A.
2. Turn the ignition switch to ON.
Does the scan tool show the ECT sensor reading
within the value specified?
≥180°C
(356°F)
Go to Step 5 Go to Step 6
5
1. Replace the ECT sensor.
2. Clear any DTCs from the ECM.
3. Perform the diagnostic system check.
Is the replacement complete?
–
System OK
–
6
Measure the voltage between ECT terminal B and
ground.
Does the voltage measure within the value
specified? 4.5–5.0V Go to Step 7 Go to Step 8
7
1. Turn the ignition switch to LOCK.
2. Disconnect the ECM wiring connector.
3. Check for a faulty connector or terminals at the
ECT sensor connector terminal A and the ECM
connector terminal 45 for an open or short to
battery voltage.
Is the problem found?
–
Go to Step 8 Go to Step 9
8
1. Turn the ignition switch to LOCK.
2. Repair the wire of the connector terminals as
needed.
3. Clear any DTCs from the ECM.
4. Run the engine until it reaches operating
temperature.
5. Perform the diagnostic system check.
Is the repair complete?
–
System OK
–
9
1. Replace the ECM.
2. Run the engine until it reaches operating
temperature.
3. Perform the diagnostic system check.
Is the repair complete?
–
Go to Step 10
–
10
Check if any additional DTCs are set.
Are any DTCs displaced that have not been
diagnosed?
–
Go to
applicable DTC
table
System OK
To Next Page
