ENGINE COOLING 1D–17
DAEWOO M-150 BL2
SPECIFICATIONS
GENERAL SPECIFICATIONS
Application Description Unit Standard Limit
Cooling
System
Cooling Type –
Forced Water
Circulation
Coolant Coolant Capacity L/qt 3.8/4.00
Thermostat Type – Pellet Type
Temperature(opened initially) °C(°F) 82(180)
Thermostat
Temperature(perfectly opened) °C(°F) 95(203.4)
Temperature(perfectly closed) °C(°F) 80(176.4)
Stroke(perfectly opened) mm(in.) 8 (0.32)
Cooling Fan Type – Electric
Blade Number EA 6
Cooling Fan Diameter mm(inch) 300(11.8)
Electric Cooling
Temperature At Low Speed ON °C(°F) 93(199.8)
Fan
Temperature At Low Speed OFF °C(°F) 90(194.4)
Temperature At High Speed ON °C(°F) 100(212.4)
Temperature At High Speed OFF °C(°F) 97(207)
Surge Tank
Open Pressure of The Pressure Valve kPa (psi)
120–150
(17.4–21.8)
Surge Tank
Open Pressure of The Vacuum Valve kPa (psi) 10 (1.5)
Water Pump Type – Centrifugal
Coolant Pump
Impeller Diameter mm(in.) 60(2.36)
Impeller Blade Number EA 7
Radiator Type – Cross–Flow
Core Width mm(in.) 458(18.03)
Radiator
Core Height mm(in.) 295(11.61)
Core Depth (Standard/Heavy Duty) mm(in.) 16/27(0.63/1.06)
Resistance
(Coolant Temperature 50°C(122.4°F))
Ω 185.2
Coolant
Temperature
Resistance
(Coolant Temperature 85°C(185.4°F))
Ω 49.2
Sensor
Resistance
(Coolant Temperature 105°C(221.4°F))
Ω 27.5
Engine Coolant
Resistance
(Coolant Temperature 20°C(68.4°F))
Ω 3,520
Temperature
Sensor
Resistance
(Coolant Temperature 80°C(176.4°F))
Ω 332
