FRONT SUSPENSION 2C–21
DAEWOO M-150 BL2
D16B718A
4. Remove the coil spring.
D Remove the strut inner support (1).
D Remove the strut mount assembly (2).
D Remove the strut mount seat (3).
D Remove the strut bearing seat (4).
D Remove the strut bearing (5).
D Remove the coil spring upper seat (6).
D Remove the coil spring seat (7).
D Remove the bumper stopper (8).
D16B719A
50–60 NSm
Assembly Procedure
1. Install the coil spring, front bumper stopper, coil
spring seat, coil spring upper seat, strut bearing,
bearing seat, mounting seat, mount assembly and in-
ner support to the strut.
2. Tighten the strut nut.
D Fix the strut support using the bench vise.
D Tighten the nut.
Tighten
Tighten the strut nut to 50–60 NSm (36–44 lb-ft).
