REAR SUSPENSION 2D–13
DAEWOO M-150 BL2
D106C704
D Remove the outer bearing race (2).
Important: Use only new bearing race.
D106C705
Assembly Procedure
1. Press the bearing race into the break drum using the
front wheel hub remover DW 340–010 and the rear
wheel bearing race installer DW 350–030.
D Press the inner bearing race (1).
D106C706
D Press the outer bearing race (2).
D106C707
2. Install the wheel bearing and oil seal into the brake
drum.
Important: Coat or fill all the hollow spaces of both
wheel bearing, the ring seal lip and the brake drum with
antifriction grease.
D Install the inner bearing (1).
D Install the oil seal (2).
