HEATING AND VENTILATION SYSTEM 7A–23
DAEWOO M-150 BL2
D108A521
Installation Procedure
1. Install the heater outlet hoses.
D Connect the heater hose to the engine (1).
D Connect the B
+
terminal to the starter. Refer to
Section 1E, Engine Electrical.
D18A522A
D Connect the hose to the heater module using a
hose installer DW100–020 (2).
D Lower the vehicle.
D108A519
2. Install the heater inlet hoses.
D Connect the hose to the thermostat (1).
D Raise and suitably support the vehicle.
DW100–020
D18A520A
D Connect the hose to the heater module using a
hose installer DW100–020 (2).
D Lower the vehicle.
D Install the air cleaner housing.
3. Refill the coolant. Refer to Section 1D, Engine Cool-
ing.
4. Connect the negative battery cable.
