7B–4 MANUAL CONTROL HEATING, VENTILATION, AND AIR CONDITIONING SYSTEM
DAEWOO M-150 BL2
1. High Pressure Pipe
(Receiver Dryer → Evaporator)
2. Low Pressure Hose
(Evaporator → Compressor)
3. O–ring
4. Evaporator Module
5. Evaporator Upper Case
6. thermistor
7. Evaporator Core
8. Expansion Valve
9. Evaporator Inlet Pipe
10. Plate
11. Evaporator Lower Case
12. O–ring
13. High Pressure Pipe
(Compressor → Condenser)
14. Compressor
15. Compressor Magnetic Clutch
16. Compressor Pulley
17. Compressor Clutch Drive
18. Shaft Bolt
19. High Pressure Pipe
(Condenser → Receiver–Dryer)
20. Condenser
21. Receiver–Dryer
22. Dual Cut Switch
23. Receiver–Dryer Bracket
24. Compressor Bracket
25. Compressor Stay
26. A/C & Power Steering Bracket
