7B–6 MANUAL CONTROL HEATING, VENTILATION, AND AIR CONDITIONING SYSTEM
DAEWOO M-150 BL2
PRESSURE-TEMPERATURE RELATIONSHIP OF R-134A
ÁÁÁÁÁÁ
TEMPERATURE
_C (_F)*
ÁÁÁÁÁÁÁ
PRESSURE
kPa (psig)*
ÁÁÁÁÁÁÁÁÁ
TEMPERATURE
_C (_F)*
ÁÁÁÁÁÁÁ
PRESSURE
kPa (psig)*
–8.89 (16)
105.70 (15.33)
37.78 (100)
856.84 (124.27)
–7.78 (18)
114.87 (16.66)
38.89 (102)
886.56 (128.58)
–6.67 (20)
124.32 (18.03)
40.00 (104)
916.35 (132.98)
–5.56 (22)
134.11 (19.45)
41.11 (106)
947.92 (137.48)
–4.44 (24)
144.24 (20.92)
42.22 (108)
979.64 (142.08)
–3.33 (26)
154.65 (22.43)
43.33 (110)
1012.11 (146.79)
–2.22 (28)
165.48 (24.00)
44.44 (112)
1045.21 (151.59)
ÁÁÁÁÁÁ
–1.11 (30)
ÁÁÁÁÁÁÁ
176.65 (25.62)
ÁÁÁÁÁÁÁÁÁ
45.56 (114)
ÁÁÁÁÁÁÁ
1079.14 (156.51)
0.00 (32)
188.16 (27.29)
46.67 (116)
1113.75 (161.53)
1.11 (34)
200.02 (29.01)
47.78 (118)
1149.12 (166.66)
2.22 (36)
212.30 (30.79)
48.89 (120)
1185.18 (171.89)
3.33 (38)
224.98 (32.63)
50.00 (122)
1222.07 (177.24)
4.44 (40)
238.08 (34.53)
51.11 (124)
1259.72 (182.70)
7.22 (45)
272.49 (39.52)
52.22 (126)
1298.12 (188.27)
10.00 (50)
309.58 (44.90)
53.33 (128)
1337.35 (193.96)
12.77 (55)
349.51 (50.69)
54.44 (130)
1377.35 (199.76)
15.56 (60)
392.33 (56.90)
57.22 (135)
1480.91 (214.78)
ÁÁÁÁÁÁ
18.33 (65)
ÁÁÁÁÁÁÁ
438.18 (63.55)
ÁÁÁÁÁÁÁÁÁ
60.00 (140)
ÁÁÁÁÁÁÁ
1589.57 (230.54)
21.11 (70)
487.27 (70.67)
62.78 (145)
1703.62 (247.08)
23.89 (75)
539.67 (78.27)
65.56 (150)
1823.04 (264.40)
26.67 (80)
609.38 (88.38)
68.33 (155)
1948.04 (282.53)
29.44 (85)
655.09 (95.01)
71.11 (160)
2078.77 (301.49)
32.22 (90)
718.39 (104.19)
73.89 (165)
2215.29 (321.29)
35.00 (95)
785.61 (113.94)
76.67 (170)
2357.81 (341.96)
* All values rounded to two decimal places.
EVAPORATOR RANGE: From –6.67 to 7.22_C (20 to 45_F), the temperatures represent the gas temperatures inside
the coil and not on the coil surfaces. Add 1.67 to 5.56_C (3 to 10_F) the temperature for coil and air-off temperatures.
CONDENSER RANGE: From 110 to 160_F, temperatures are not ambient. Add 19.4 to 22.2_C (35 to 40_F) for proper
heat transfer, then refer to the pressure chart.
Example: 32_C (90_F) ambient temperature
+22_C (40_F)
54_C (130_F)
Condenser temperature = 1379 kPa (200 psig)
Based on 48.3 km/h (30 mph) air flow.
