ESIE11-02 General Outline
Part 1 – System Outline 1–3
3
1
4
5
Part 1
1 General Outline
1.1 What Is in This Chapter?
Introduction This chapter contains the following information:
■ Technical specifications
■ Electrical specifications
■ Installation outline of a typical installation
■ Outlook drawings: Outlook, dimensions, installation and service space.
Overview This chapter contains the following topics:
Topic See page
1.2–Technical Specifications: EUWA*5-8KBZW1 1–5
1.3–Technical Specifications: EUWA*10-12KBZW1 1–8
1.4–Technical Specifications: EUWA*16-20KBZW1 1–11
1.5–Technical Specifications: EUWA*24KBZW1 1–14
1.6–Technical Specifications: EUWY*5-8KBZW1 1–17
1.7–Technical Specifications: EUWY*10-12KBZW1 1–20
1.8–Technical Specifications: EUWY*16-20KBZW1 1–23
1.9–Technical Specifications: EUWY*24KBZW1 1–26
1.10–Correction factors for glycol 1–29
1.11–Electrical Specifications: EUWA*5-8KBZW1 1–31
1.12–Electrical Specifications: EUWA*10-12KBZW1 1–33
1.13–Electrical Specifications: EUWA*16-20KBZW1 1–35
1.14–Electrical Specifications: EUWA*24KBZW1 1–37
1.15–Electrical Specifications: EUWY*5-8KBZW1 1–39
1.16–Electrical Specifications: EUWY*10-12KBZW1 1–41
1.17–Electrical Specifications: EUWY*16-20KBZW1 1–43
1.18–Electrical Specifications: EUWY*24KBZW1 1–45
1.19–Outlook Drawing: EUWAN5-8KBZW1/EUWYN5-8KBZW1 1–47
1.20–Outlook Drawing: EUWAP5-8KBZW1/EUWYP5-8KBZW1 1–48
1.21–Outlook Drawing: EUWAB5-8KBZW1/EUWYB5-8KBZW1 1–49
1.22–Outlook Drawing: EUWAN10-12KBZW1/EUWYN10-12KBZW1 1–50
