ESIE11-02 Pre-Test Run Checks
Part 4 – Commissioning and Test Run 4–5
3
4
5
1
1.3 Water Piping Checks
Checklist The table below contains the water piping checklist.
Water volume, flow
and pressure
The table below shows the operation range of water volume and water flow for proper operation of the
unit.
The water pressure should not exceed the maximum working pressure of 10 bar.
Step Check whether...
1 A filter is installed in front of the water inlet of the plate-heat exchanger. The plate-heat
exchangers are sensitive to dirt and small particles.
2 The water volume is within the limits.
3 There is adequate water flow.
4 The water quality meets the standards.
5 The water piping is properly insulated.
6 Measurement points for temperature and pressure are available on the water circuit.
7 The flow switch and pump are properly working.
8 Air purge points are installed on the high parts of the water piping.
9 Drain taps are installed at the low points of the water piping.
10 Other parts of the water circuit are properly mounted and installed (e.g. buffer tank, expan-
sion tank...).
11 Vibration compensators are mounted at the water connections if the unit is positioned on
anti-vibration pads.
Chiller type Minimum water volume Minimum water flow
Maximum water
flow
EUWA*5KBZW1 54 l 16.2 l/min 64.9 l/min
EUWA*8KBZW1 85 l 25.6 l/min 102.5 l/min
EUWA*10KBZW1 108 l 32.2 l/min 128.9 l/min
EUWA*12KBZW1 126 l 37.9 l/min 151.6 l/min
EUWA*16KBZW1 88 l 53 l/min 212 l/min
EUWA*20KBZW1 111 l 67 l/min 267 l/min
EUWA*24KBZW1 132 l 79 l/min 317 l/min
EUWY*5KBZW1 43 l 21 l/min 68 l/min
EUWY*8KBZW1 82 l 31 l/min 106 l/min
EUWY*10KBZW1 100 l 38 l/min 137 l/min
EUWY*12KBZW1 119 l 45 l/min 155 l/min
EUWY*16KBZW1 82 l 61 l/min 212 l/min
EUWY*20KBZW1 100 l 75 l/min 275 l/min
EUWY*24KBZW1 119 l 89 l/min 309 l/min
