1.2 Technical Specifications: EUWA*5-8KBZW1
Technical
specifications
The table below contains the technical specifications.
Model EUWAN5KBZW1 EUWAP5KBZW1 EUWAB5KBZW1 EUWAN8KBZW1 EUWAP8KBZW1 EUWAB8KBZW1
Nominal cooling
capacity
11.3 kW 17.9 kW
Nominal input
4.52 kW 4.64 kW 7.38 kW 7.39 kW
Capacity steps
0-100% 0-100%
Compressor
Type Hermetically sealed scroll Hermetically sealed scroll
Speed 2900 rpm 2900 rpm
Crankcase heater 33 W 50 W
No. x model (W1) 1 x JT140BF-YE 1 x JT212DA-YE
Evaporator
Type Brased plate-heat exchanger Brased plate-heat exchanger
No. x model 1 x AC70X-24HX 1 x AC70X-34HX
Min.water volume
in the system
(1)
54 l 85 l
Water flow rate Min.: 16 l/min
Max.: 65 l/min
Min.: 26 l/min
Max.: 102 l/min
Nominal water flow 32 l/min 51 l/min
Nom. water
pressure drop
24 kPa 38 kPa
Insulation material Climaflex
Condenser
Type Cross fin coil Hi-X tubes and PE coated waffle louvre fins
Rows x stages x fin
pitch
2x40x2.0mm
Face area 1.570 m²
Nominal air flow 160 m³/min 170 m³/min
Discharge Vertical
Fan type Direct drive
No. of fans 2
No. of motors x
output
2 x 140 kW 1 x 190 kW and 1 x 230 kW
Piping connections
Evap. water
in/outlet
FBSP 1-1/4” FBSP 1-1/4”
Refrigerant circuit
Refrigerant type R-407C
Refrigerant charge 3.9 kg 4.6 kg
Refrigerant control Thermostatic expansion valve
Oil type Idemitsu FVC 68D
Oil charge volume 1.5 l 2.7 l
