ESIE11-02 Piping Layout
Part 1 – System Outline 1–59
3
1
4
5
Part 1
2 Piping Layout
2.1 What Is in This Chapter?
Introduction This chapter describes the internal refrigeration circuit. The water piping is considered to be a common
practice and is, therefore, not described.
Overview This chapter contains the following topics:
Topic See page
2.2–Installation outline 1–60
2.3–Functional Diagram Refrigeration Circuit: EUWA*5-24KBZW1 1–61
2.4–Functional Diagram Refrigeration Circuit: EUWY*5-24KBZW1 1–64
