ESIE11-02 General Outline
Part 1 – System Outline 1–17
3
1
4
5
1.6 Technical Specifications: EUWY*5-8KBZW1
Technical
specifications
The table below contains the technical specifications.
Model EUWYN5KBZW1 EUWYP5KBZW1 EUWYB5KBZW1 EUWYN8KBZW1 EUWYP8KBZW1 EUWYB8KBZW1
Nominal capacity Cooling: 9.1 kW
Heating: 11.9 kW
Cooling: 17.1 kW
Heating: 18.5 kW
Nominal input
Cooling: 3.78 kW
Heating: 4.59 kW
Cooling: 7.45 kW
Heating: 7.10 kW
Cooling: 7.46 kW
Heating: 7.10 kW
Capacity steps
0-100%
Compressor
Type Hermetically sealed scroll
Speed 2900 rpm
Crankcase heater 33 W 50 W
No. x model (W1) 1 x JT140BF-YE 1 x JT212DA-YE
Evaporator
Type Brased plate-heat exchanger
No. x model 1 x AC70X-34HX 1 x AC70X-40HX
Min.water volume
in the system
(1)
43 l 82 l
Water flow rate Min.: 21 l/min
Max.: 68 l/min
Min.: 31 l/min
Max.: 106 l/min
Nominal water flow Cooling: 26 l/min
Heating: 34 l/min
Cooling: 49 l/min
Heating: 53 l/min
Nom. water
pressure drop
Cooling: 10 kPa
Heating: 17 kPa
Cooling: 25 kPa
Heating: 29 kPa
Insulation material Climaflex
Condenser
Type Cross fin coil Hi-X tubes and PE coated waffle louvre fins
Rows x stages x fin
pitch
2x40x2
Face area 1.570 m²
Nominal air flow 160 m³/min 170 m³/min
Discharge Vertical
Fan type Direct drive
No. of fans 2
No. of motors x
output
2 x 140 kW 1 x 190 kW and 1 x 230 kW
Piping connections
Evap. water
in/outlet
FBSP 1-1/4”
Refrigerant circuit
Refrigerant type R-407C
Refrigerant charge 4.6 kg 4.7 kg
Refrigerant control Thermostatic expansion valve
Oil type Idemitsu FVC 68D
