Checking the Inputs and Outputs ESIE11-02
3–16 Part 3 – Troubleshooting
3
1
3
4
5
3.4 I/O PCB sensors: R6T, R7T and R8T for EUWA*5-24KBZW1 and
EUWY*5-24KBZW1
Temp.-resistance The table below contains the temperature resistance values of the I/O PCB sensors R6T, R7T and
R8T.
Temp. (°C)
Resistance (kΩ)
Temp. (°C)
Resistance (kΩ)
Temp. (°C)
Resistance (kΩ)
At x.0°C At x.5°C At x.0°C At x.5°C At x.0°C At x.5°C
-20 197.81 192.08 14 33.02 32.25 48 7.75 7.60
-19 186.53 181.16 15 31.50 30.77 49 7.46 7.31
-18 175.97 170.94 16 30.06 29.37
50 7.18 7.04
-17 166.07 161.36 17 28.70 28.05 51 6.91 6.78
-16 156.80 152.38 18 27.41 26.78 52 6.65 6.53
-15 148.10 143.96 19 26.18 25.59 53 6.41 6.53
-14 139.94 136.05
20 25.01 24.45 54 6.65 6.53
-13 132.28 128.63 21 23.91 23.37 55 6.41 6.29
-12 125.09 121.66 22 22.85 22.35 56 6.18 6.06
-11 118.34 115.12 23 21.85 21.37 57 5.95 5.84
-10 111.99 108.96 24 20.90 20.45 58 5.74 5.43
-9 106.03 103.18 25 20.00 19.56 59 5.14 5.05
-8 100.41 97.73 26 19.14 18.73
60 4.96 4.87
-7 95.14 92.61 27 18.32 17.93 61 4.97 4.70
-6 90.17 87.79 28 17.54 17.17 62 4.62 4.54
-5 85.49 83.25 29 16.80 16.45 63 4.46 4.38
-4 81.08 78.97
30 16.10 15.76 64 4.30 4.23
-3 76.93 74.94 31 15.43 15.10 65 4.16 4.08
-2 73.01 71.14 32 14.79 14.48 66 4.01 3.94
-1 69.32 67.56 33 14.18 13.88 67 3.88 3.81
0 65.84 64.17 34 13.59 13.31 68 3.75 3.68
1 62.54 60.96 35 13.04 12.77 69 3.62 3.56
2 59.43 57.94 36 12.51 12.25
70 3.50 3.44
3 56.49 55.08 37 12.01 11.76 71 3.38 3.32
4 53.71 52.38 38 11.52 11.29 72 3.27 3.21
5 51.09 49.83 39 11.06 10.84 73 3.16 3.11
6 48.61 47.42
40 10.63 10.41 74 3.06 3.01
7 46.26 45.14 41 10.21 10.00 75 2.96 2.91
8 44.05 42.98 42 9.81 9.61 76 2.86 2.82
9 41.95 40.94 43 9.42 9.24 77 2.77 2.72
10 39.96 39.01 44 9.06 8.88 78 2.68 2.64
11 38.08 37.18 45 8.71 8.54 79 2.60 2.55
12 36.30 35.45 46 8.37 8.21
80 2.51 2.47
13 34.62 33.81 47 8.05 7.90 —
