ESIE11-02 Functional Description
Part 2 – Functional Description 2–13
3
2
4
5
1
1.9 Fan Working: EUWA*5-24KBZW1 and EUWY*5-24KBZW1
Working principle The fan runs parallel with the compressor operation. The operation is not steered by the microchiller
controller but by the I/O PCB.
See “Head Pressure Control: EUWA*5-24KBZW1 and EUWY*5-24KBZW1” on page 2-11.
