ESIE11-02 General Outline
Part 1 – System Outline 1–11
3
1
4
5
1.4 Technical Specifications: EUWA*16-20KBZW1
Technical
specifications
The table below contains the technical specifications.
Model EUWAN16KBZW1 EUWAP16KBZW1 EUWAB16KBZW1 EUWAN20KBZW1 EUWAP20KBZW1 EUWAB20KBZW1
Nominal cooling
capacity
37.0 kW 46.6 kW
Nominal input
15.2 kW 15.0 kW 18.1 kW 17.9 kW
Capacity steps
0%-50%-100%
Compressor
Type Hermetically sealed scroll
Speed 2900 rpm
Crankcase heater 50 W
No. x model (W1) 2 x JT212DA-YE 2 x JT265DA-YE
Evaporator
Type Brased plate-heat exchanger
No. x model 1 x AC230X-38HX 1 x AC230X-50HX
Min.water volume
in the system
(1)
88 l 111 l
Water flow rate Min.: 53 l/min
Max.: 212 l/min
Min.: 67 l/min
Max.: 267 l/min
Nominal water
flow
106 l/min 134 l/min
Nom. water
pressure drop
22 kPa
Insulation material Climaflex
Condenser
Type Cross fin coil Hi-X tubes and PE coated waffle louvre fins
Rows x stages x
fin pitch
2x40x2mm 2x50x2mm
Face area 2 x 1.570 m² 2 x 1.970 m²
Nominal air flow 2 x 170 m³/min
Discharge Vertical
Fan type Direct drive
No. of fans 4
No. of motors x
output
2 x 190 kW + 2 x 230 kW
Piping connections
Evap. water
in/outlet
FBSP 2”
Refrigerant circuit
Refrigerant type R-407C
Refrigerant charge 2 x 4.6 kg __ 2 x 5.9 kg __
Refrigerant control Thermostatic expansion valve
Oil type Idemitsu FVC 68D
