Mounting the BC9xx0 Cradle
Product Reference Guide
13
Connecting and Disconnecting the Interface Cable
The BC9xx0 can be connected to a Host by means of a multi-interface cable,
which must be simply plugged into the Host connector, visible on the front
panel of the cradle.
To disconnect the cable, insert a paper clip or other similar object into the
ho
le corresponding to the Host connector on the body of the cradle. Push
down on the clip while unplugging the cable. Refer to the following figures:
Power
Interface Emulation to Host
Connecting/Disconnecting the Cable
RS-232
USB*
*The power supply is optional, the cradle can be powered by the USB port. In
this case the full charging of an empty battery will take about 10 hours. For
intense usage and/or when the system is shut down during the night, the
use of an external power supply is recommended.
WEDGE
To Next Page
