Figure 77. Installing the mini Mezzanine card
5 Close the lever on the mini Mezzanine card.
Next step
1 Follow the procedure listed in After working inside your sled.
Removing the mini Mezzanine card blank
Prerequisites
CAUTION
: To ensure proper system cooling, the mini Mezzanine blank must be installed in the mini Mezzanine socket.
NOTE: The removal of the blank is recommended only if you intend to install a mini Mezzanine card in the socket.
1 Follow the safety guidelines listed in Safety Instructions.
2 Follow the procedure listed in Before working inside the sled.
Step
Lift the mini Mezzanine card blank from the slot to remove it from the system.
104
Installing and removing system components
