Installing and removing system components
Safety instructions
WARNING: Whenever you need to lift the system, get others to assist you. To avoid injury, do not attempt to lift the system by
yourself.
WARNING: Opening or removing the system cover while the system is powered on may expose you to a risk of electric shock.
CAUTION: Do not operate the system without the cover for a duration exceeding ve minutes. Operating the system without the
system cover can result in component damage.
CAUTION: Many repairs may only be done by a certied service technician. You should only perform troubleshooting and simple
repairs as authorized in your product documentation, or as directed by the online or telephone service and support team.
Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions
that are shipped with your product.
NOTE: It is recommended that you always use an antistatic mat and antistatic strap while working on components inside the
system.
CAUTION: To ensure proper operation and cooling, all bays in the system and system fans must be always populated with a
component or a blank.
Before working inside your sled
Prerequisite
Follow the safety guidelines listed in Safety instructions.
Steps
1 Power o the sled.
2 Remove the sled from the enclosure.
3 If applicable install the I/O connector cover.
CAUTION
: To prevent damage to the I/O connectors on the system, ensure that you cover the connectors when you
remove the system from the enclosure.
4 Remove the system cover.
After working inside your sled
Prerequisite
Follow the safety guidelines listed in Safety instructions.
Steps
1 Install the system cover.
2 If installed, remove the I/O connector cover on the system.
CAUTION
: To prevent damage to the I/O connectors, do not touch the connectors or the connector pins.
3 Install the sled in the enclosure.
4 Power on the sled.
5
Installing and removing system components 41
