Figure 38. Cable routing - 6 x 2.5-inch backplane with Jumbo PERC card
Figure 39. Cable routing - 6 x 2.5-inch backplane SATA cabling
Drive cage
The drive cage contains the drives and the battery backup unit module.
Removing the drive cage
Prerequisites
CAUTION
: To prevent damage to the drives and backplane, you must remove the drives from the system before removing the
backplane.
62 Installing and removing system components
