Trusted Platform Module
Trusted Platform Module (TPM) is a dedicated microprocessor designed to secure hardware by integrating cryptographic keys into devices.
Software can use a TPM to authenticate hardware devices. Because each TPM chip has a unique and secret RSA key which is embedded
during the manufacture of the TPM, it is capable of performing platform authentication operation.
Upgrading the TPM
Prerequisites
1 Follow the safety guidelines listed in Safety instructions.
2 Follow the procedure listed in Before working inside your sled.
3 Disconnect the cables.
4 Remove the drive backplane.
NOTE:
• Ensure that your operating system supports the version of the TPM module being installed.
• Ensure that you download and install the latest BIOS rmware on your system.
• Ensure that the BIOS is congured to enable UEFI boot mode.
About this task
CAUTION
: If you are using the Trusted Platform Module (TPM) with an encryption key, you may be prompted to create a
recovery key during program or System Setup. Work with the customer to create and safely store this recovery key. When
replacing this system board, you must supply the recovery key when you restart your system or program before you can access
the encrypted data on your hard drives.
CAUTION: After the TPM plug-in module is installed, it is cryptographically bound to that specic system board. Any attempt to
remove an installed TPM plug-in module breaks the cryptographic binding, the removed TPM cannot be reinstalled or installed on
another system board.
Removing the TPM
1 Locate the TPM connector on the system board.
To locate the TPM connector, see System board jumpers and connectors.
2 Press to hold down the module and remove the screw using the security Torx 8-bit shipped with the TPM module.
3 Slide the TPM module out from its connector.
4 Push the plastic rivet away from the TPM connector and rotate it 90° counterclockwise to release it from the system board.
5 Pull the plastic rivet out of its slot on the system board.
Installing the TPM
Steps
1 To install the TPM, align the edge connectors on the TPM with the slot on the TPM connector.
2 Insert the TPM into the TPM connector such that the plastic rivet aligns with the slot on the system board.
3 Press the plastic rivet until the rivet snaps into place.
Installing and removing system components
115
