Installing Blade Components 185
System Memory – PowerEdge M605
You can upgrade your system memory to a maximum of 16 GB (single
processor) or 32 GB (dual processors) by installing 667 or 800 MHz registered
DDR2 memory modules in sets of 512 MB, 1 GB, 2 GB, 4 GB, or 8 GB
modules. Each processor has four memory channels, organized in sets of two
channels.
96 GB Twelve 8 GB
RDIMMs
A1, A2, A3, A4,
A5, A6, B1, B2,
B3, B4, B5, B6
Two Independent
channel
96 GB
128 GB Eight 16 GB
RDIMMs
A2, A3, A5, A6,
B2, B3, B5, B6
Two Mirroring 64 GB
128 GB Eight 16 GB
RDIMMs
A2, A3, A5, A6,
B2, B3, B5, B6
Two Advanced
ECC
128 GB
192 GB Twelve 16 GB
RDIMMs
A1, A2, A3, A4,
A5, A6, B1, B2,
B3, B4, B5, B6
Two Independent
channel
192 GB
Table 3-9. Examples of PowerEdge M610/M610x Memory Configurations
(continued)
Total
Physical
Memory
Memory Modules
– Number and
Type
Memory Module
Locations
Processors Memory
Mode
Available
Memory
