System Board Information 309
7
System Board Information
Blade System Board Jumper Settings
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not covered
by your warranty. Read and follow the safety instructions that came with the
product.
PowerEdge M910 Jumper Settings
Figure 7-1 shows the location of the configuration jumpers on the blade
system board. Table 7-1 lists the jumper settings.
NOTE: Figure 7-1 is oriented with the front end of the blade system board facing to
the right.
Table 7-1. PowerEdge M910 Jumper Settings
PSWD_EN (default) The password feature is enabled.
The password feature is disabled.
NVRAM_CLR (default) The configuration settings are retained at
system boot.
The configuration settings are cleared at the
next system boot. (If the configuration settings
become corrupted to the point where the
system does not boot, install the jumper and
boot the system. Remove the jumper before
restoring the configuration information.)
